mt-s905 is a quad core hevc 4k@60fps android ott/iptv set-top box.it is designed for isps,ott
operators and content aggregators that provide services based on iptv,ott and vod.
arm cortex-a53 quad core cpu,android 5.1
4k@30fps hevc main-10 decoding
drm:widevine,playready,verimatrix,marlin
support pppoe、dhcp、lan multiple access methods.
support ipv4/ipv6
support ieee 802.11b/g/n
support bluetooth 4.0
support 10/100mbps ethernet rj45 port
support  2*usb port
support 1* cvbs
support 1*spdif
support  one  micro sd card interface


product specification
processor cpu arm cortex-a53 quad core cpu
gpu penta-core arm mali-450 gpu up to 750mhz (dvfs)
dual geometry processors and triple pixel processors
system ui android
os android 5.1
memory dram 2gb,ddr3
flash 8gb,emmc
interface power 12v,1a
usb usb2.0 x2,support mouse&keyboard
ethernet rj45
hdmi hdmi2.0,video output
spdif fiber audio output
sd card tf card
mini av 1 to 3 (3.5mm)
network wi-fi wi-fi 2.4ghz 300m ieee 802.11b/g/n
bluetooth bluetooth 4.0
ir internal ir receiver
ethernet rj45 interface 10m/100m ieee 802.3u
video format avi,flv,iso,m2ts,mkv,mov,mp4,mpg,mpeg,rm,rmvb,ts,vob,wmv,dat,3gp,divx,f4v,asf,m2v etc.
decoder h.265 4k*2k@60fps,h.264 4k*2k@30fps,avs ,mpeg1/2/4 asp,wmv/vc-1,realmedia8/9/10
max resolution 1080p
audio format mp3, wma, wav, ogg, m4a, mp4, aac, ape, flac, mp1/2 etc.
decoder mpeg1/2/4, mp3, aac/aac , wma/wma-pro,  flac, ogg etc.
support dobby(optional)&dts(optional)
photo format gif,jpg,jpeg,bmp,png etc.
power
consumption
consumption 8w max
environment operation
temperature
0~40℃
humidity 5~95(%rh)
accessory
list
accessory 4k iptv box
  remote control
  battery
  power adapter
  hdmi cable
  user manual
  size 110*110*21.5mm
  material plastic
  color black,white,
accessory
list
accessory 4k iptv box
remote control
battery
power adapter
hdmi cable
mini av cable
user manual
